Understanding Tire Sidewall Markings


Understanding Tire Sidewall
Markings

Ever wonder what all of the letters and numbers mean on the sidewall of your tires? There may be much more information on your tires than you realize. Aside from the brand, model and size of the tire there are also U.S. Department of Transportation (DOT) and safety standard markings. These indicate that the tire meets the safety requirements as determined by the DOT. Along with these markings, there is the Uniform Tire Quality Grading (UTQG) code as well as load, speed and maximum inflation pressure specifications – just to name a few. Let’s take a closer look.

Shop Our Entire Selection of Tires

Click to Shop Tires

Tire Size Markings

How to read tire size

P =

Passenger Car Tire

The first letter indicates the tire’s class. P designates this tire as a passenger car tire. An LT before the tire size would mean the tire is a light truck tire. A European metric tire would have no letter before the tire size.

245 =

Section Width
Tread (mm)

The section width is the width of the tire from one sidewall to the other measured in millimeters. In this example the tire is 245 millimeters wide.

45 =

Aspect Ratio
(Ratio of Sidewall height to width)

The aspect ratio refers to the height of the sidewall. It is a percentage of the section width. In this example, the sidewall height is 45% of the 245 section width which equals 127.5.

Z =

Speed Rating
S = 112mph
T = 118mph

The speed rating designates the maximum speed at which a properly installed and inflated tire can be driven on. In this example, the speed rating is Z which means it has the highest speed rating. Z rated tires will also have a W or Y speed rating indication after the load index which denotes the actual mph the tire is rated for.

R =

Radial
Construction

In this example, the R designates this tire as a radial tire. Radial tires have layers of fabric whose cords run at right angles to the circumference of the tire and whose tread is strengthened by additional layers around the circumference making it the most common type of automotive tire.

19 =

Wheel
Diameter
(inches)

Wheel Diameter specifies the size, in inches, of the wheel that a tire fits. In this example, the tire will fit a 19 inch wheel.

98 =

Load
Index

Load Index indicates the maximum load carrying capacity of the tire. It is very important to only install tires with a load index that meets or exceeds your vehicle manufacturer’s specification.

W =

Speed
Rating

The speed rating designates the maximum speed at which a properly installed and inflated tire can be driven on. In this example, the speed rating is W which means it can be driven at speeds up to 168 mph.

U.S. Department of Transportation Markings

Department of Transportation (DOT) markings

All tires must have a DOT, Department of Transportation number which indicates the tire has passed all minimum DOT standards for sale in the U.S. This code represents the manufacturer and the plant it was manufactured at (R8) and the size (LN). Also, an optional code for manufacturing (LMJR) which specifies the construction, tread pattern and category of the tire.The week (46) and year (10) the tire was produced are at the end of the code.

Uniform Tire Quality Grading (UTQG) Marking

Uniform Tire Quality Grading (UTQG) markings

The Department of Transportation requires each manufacturer to grade its tires under the Uniform Tire Quality Grade (UTQG) system which establishes ratings for treadwear, traction and temperature resistance. It is important to note that these tests are conducted independently by each manufacturer and not by the Department of Transportation.

The treadwear rating (440) refers to the durability of the tire, not necessarily the projected life of the tire. Since the test is conducted by each manufacturer, and the grade is assigned after the tire has only experienced a small amount of treadwear, there is room for interpretation. While it may be helpful to compare treadwear grades within the same manufacturer, it might not be as helpful to compare the grades across multiple brands or manufacturers.

The traction rating (A) refers to the tire’s ability to stop in a straight line on wet asphalt and concrete under the controlled conditions of the test track. The test does not measure the tire’s cornering ability or hydroplaning resistance in wet conditions or braking and handling in dry conditions. The traction grades consist of AA, A, B or C, with AA being the highest

The temperature rating (A) refers to the tire's resistance to the generation of heat when driven at high speeds. The grades range from A through C with A being the highest, making tires with an A grade most effective at dissipating heat.

Maximum Inflation Pressure and Load

Maximum inflation pressure and load carrying capacity

This maximum inflation pressure number, (51 PSI) indicates the maximum air pressure the tire can hold while in operation. This does not represent the recommended inflation pressure for the vehicle it is installed on. You should always set your air pressure to your vehicle manufacturer’s specifications as stated in your owner’s manual or on the tire information placard inside the vehicle.

The maximum load number, (1653 LBS) is the load carrying capacity of the tire when it is inflated to the maximum inflation pressure. Similar to inflation pressure, this is not the recommended load carrying capacity for the vehicle it is installed on. You should always match the load index or load range of the tire to the specifications in your owner’s manual.
